NET ROUTER WIRELESS 300N TP-LINK TL-WR841N

WIRELESS
Standards Wi-Fi 4
IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds N300
2.4 GHz: 300 Mbps (802.11n)
WiFi Range 2 Bedroom Houses
2× Fixed Antennas
WiFi Capacity Legacy
Working Modes Router Mode
Access Point Mode
Range Extender Mode
WISP Mode
HARDWARE
Processor Single-Core CPU
Ethernet Ports 1× 10/100 Mbps WAN Port
4× 10/100 Mbps LAN Ports
Buttons Reset Button
Power 9 V ⎓ 0.6 A
SECURITY
WiFi Encryption WEP
WPA
WPA2
WPA/WPA2-Enterprise (802.1x)
Network Security SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
Guest Network 1× 2.4 GHz Guest Network
SOFTWARE
Protocols IPv4
IPv6
Parental Controls URL Filtering
Time Controls
WAN Types Dynamic IP
Static IP
PPPoE
PPTP
L2TP
Quality of Service QoS by Device
NAT Forwarding VIrtual Server
Port Forwarding
Port Triggering
DMZ
UPnP
IPTV IGMP Proxy
IGMP Snooping
DHCP Address Reservation
DHCP Client List
Server
DDNS NO-IP
Comex
DynDNS
Management Tether App
Webpage
OTHER
System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet access)
Certifications FCC
Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
TEST DATA
WiFi Transmission Power FCC:
<30dBm
WiFi Reception Sensitivity 270M: -70dBm@10% PER
130M: -74dBm@10% PER
108M: -74dBm@10% PER
54M: -77dBm@10% PER
11M: -87dBm@8% PER
6M: -90dBm@10% PER
1M: -98dBm@8% PER
PHYSICAL
Dimensions (W×D×H) 6.9 × 4.6 × 1.3 in
(173 × 118 × 33mm)
Package Contents Wi-Fi Router TL-WR841N
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
